General |
Dimension | 77 mm (3.03″) x60.5 mm (2.38″) x34.44 mm (1.36″) without tripod
130 mm (5.1″) x 115 mm (4.5″) x 138.5 mm (5.5″) with tripod |
Weight | 123.2 g without tripod
178.2 g with tripod |
Water rating | IPX7 |
Display Type | Sunlight-visible, transflective, monochrome |
Display Size | 33 mm x 44 mm (1.3″ x 1.7″), 55 mm diagonal (2.2″) |
Display Resolution | 240 x 320 pixels |
Battery type | Internal rechargeable lithium-ion battery |
Battery life | Up to 6 hours |
Operating range | -10° C to 55° C (14° F to 131° F) |
Memory/History | 200 sessions before a ShotView™ app sync is required to save data to phone |
Interface | USB-C |
Chronograph features |
Tracks rifles up to 1524 mps / 5000 FPS | |
Tracks bows and crossbows up to 182 mps / 600 FPS | |
Track pistols up to 1524 mps / 5000 FPS | |
Tracks air rifles up to 609 mps / 2000 FPS | |
Tracks airsoft up to 304 mps / 1000 FPS | |
Track other projectiles up to 1524 mps / 5000 FPS | |
Calculates kinetic energy at muzzle | |
Calculates power factor | |
Calculates extreme spread | |
Calculates standard deviation | |
Calculates string average | |
Delete shots in string | Device or app |
Decimal precision | |
Add individual shot notes | yes (on ShotView™ app) |
Add session notes | yes (on ShotView™ app) |
Mark shots with clean/cold bore | yes (on ShotView™ app) |
Exclude shot from average and standard dev calculations | Device or app |
Tripod compatibility | yes (¼-20 thread compatible) |
